Biotrium

Product Specifications

Feature Description
Stent Material Cobalt Chromium Alloy (L605)
Drug Sirolimus (Rapamycin)
Polymer Dual Polymer PLGA Coating System
Strut Thickness 65 μm (0.065 mm / 0.0026")
Stent Diameter (mm) 2.00, 2.25, 2.50, 2.75, 3.00, 3.50, 4.00, 4.50
Stent Length (mm) 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, 48
Delivery System Rapid Exchange (Rx)
Balloon Type Semi-Compliant
Entry profile 0.016"/0.41 mm
Usable Catheter Length 140 cm
Proximal Shaft Diameter 1.98F
Distal shaft Diameter 2.7F
Balloon Marker material Platinum-Iridium
Nominal Pressure 7 atm
Rated Burst Pressure 16 atm for diameter 2.00mm to 3.00mm
14 atm diameter 3.50mm to 4.50mm
Min.Guide Catheter I.D. 5F (Min. I.D. 0.056" / 1.42 mm)

Key Features

• Ultra-thin CoCr platform ensures exceptional flexibility and high radial strength.


• Biodegradable polymer technology provides controlled Sirolimus elution and rapid vascular healing.


• Clinically proven drug formulation prevents restenosis to ensure long-term vessel patency.


• Low-profile delivery system features a soft tapered tip for superior lesion crossability.


• Hydrophilic-coated shaft enables smooth, low-friction navigation through tortuous anatomy.


• Nylon balloon and dual radiopaque markers guarantee uniform expansion and precise placement.

Product Information

  • Product:

    Biotrium-Sirolimus Eluting Coronary Stent System
  • Variants:

    Sirolimus Eluting Coronary Stent System
  • Rating:
