High Pressure Tubing

Specifications

Specifications Eion Flow
Tubing Material Medical-grade DEHP-free PVC
Inner Diameter .071” (1.8mm)
Pressure Rating 1000 PSI (70 Bar), 500 PSI (34 Bar)
Fluid Capacity
25 cm10” Length0.71 ml
50 cm20” Length1.36 ml
100 cm39” Length2.59 ml
120 cm48” Length3.18 ml
150 cm59” Length3.88 ml
200 cm79” Length5.10 ml
Sterilization Method EO
Packaged Straight 25 units per box, 4 boxes per case

CLEAR, PVC CONTRAST INJECTION LINE RATED AT 1000 PSI (70 BAR)
1000 PSI (70 Bar) 10” (25 cm) 20” (50 cm) 39” (100 cm) 48” (120 cm) 59” (150 cm) 79” (200 cm)
Cat No’s EFLB25 EFLB50 EFLB100 EFLB120 EFLB150 EFLB200

CLEAR, PVC CONTRAST INJECTION LINE RATED AT 500 PSI (34 BAR)
500 PSI (34 Bar) 10” (25 cm) 20” (50 cm) 39” (100 cm) 48” (120 cm) 59” (150 cm) 79” (200 cm)
Cat No’s EFLC25 EFLC50 EFLC100 EFLC120 EFLC150 EFLC200

Range Pressure Rating Construction Type Tubing Material Inner Layer / Lumen Reinforcement Connector Material Typical Use Case
EION FLOW 1000 psi Non-Braided Value Medical-Grade DEHP-Free PVC (Economy PU) Standard Smooth PVC/PU Blend None ABS or Polypropylene Routine cardiology, ICU, medication/contrast delivery
EION FLOW 500 psi Standard Pressure Line Medical-Grade DEHP-Free PVC Standard PVC None Polypropylene / ABS ICU/ward pressure monitoring, general use

Product Key features

• Reliable Everyday Performance

Stable flow for routine infusion & monitoring.

• Soft, Flexible PVC

Comfortable handling and easy patient positioning.

• Smooth Rotating Luer-Lock

Secure fit; prevents line twisting.

• Consistent Flow Pathway

Minimal resistance for accurate delivery.

• Radiopaque Indicator Line

Basic visibility for placement confirmation.

• EO Sterile & Ready to Use

Safe for wards, ICUs .


Packaging

  • Packaged Straight 25 units per box, 4 boxes per case

Product Information

  • Product:

    High Pressure Tubing

  • Size

    25, 50, 100, 120, 150, and 200 cm

  • Variants:

    Eion Flow

  • Rating:
